Showing your Ford Mondeo radio serial code on the radios display.
Turn on your radio and hold the preset buttons 1 & 6 for 2 to 3 seconds, the code cycle will begin, wait until your serial shows and make note. It will look like the image below .
If buttons 1 & 6 do not work, try holding button presets 2 & 6. The radio serial will display on screen.
To obtain your Ford Mondeo radio serial, hold buttons 1 & 6 together to start a code cycle. The 'V'/'M' serial will display towards the end of the cycle. For example V197905
If you do not see the serial try holding buttons 2 & 6 and look out for a serial starting with the letter 'M'. If neither of these work please refer to method 2 below. For example M197905
How to Find Your Ford Mondeo Radio Code Serial Number on the Label.
Once you have the radio release keys, push them into the 4 holes in each corner of the radio (See image), apply a little pressure and the radio will release from the dashboard. The radios label will be located on the radio's casing.
The Ford radio serial starts with V/M/BP/C7 for example V123456. The TravelPilot models are a longer serial number. An example of this would be C73F0961 C 0536857. If your radio is a TravelPilot, please see our Ford TravelPilot page. Please see images below for reference.
Popular radios such as the 6000CD, 4000 RDS & 6006CD are removed using radio removal keys.
All keys are on amazon which are inexpensive.
Push the keys into each corner of the radio until they click into place.
This will free the unit to be pulled forwards and the label will look similar to the following example.
The Sony MP3, 6000CD Mk2, & 4500 RDS systems are slightly different but just as easy.
You will need a prying tool to remove the plastic trim surrounding the radio as the example shows.
Also require is a Phillips screwdriver, to remove the four screws holding the radio in place.
